MOVING PARTS Tata LPT 613 LHD EURO II - ООО «ВТМ» - автозапчасти для грузовых автомобилей id: 9

Каталог запасных частей к технике: Tata LPT 613 LHD EURO II (справочная информация). MOVING PARTS

Позиция на иллюстрации	Заводской номер детали	Название детали
BEARING HALF	BEARING HALF	BEARING HALF (UPPER & LOWER) STD
BEARING HALF	BEARING HALF	BEARING HALF (UPPER & LOWER) STD
BEARING HALF	BEARING HALF	BEARING HALF (UPPER & LOWER) STD
BEARING HALF	BEARING HALF	BEARING HALF (UPPER & LOWER) STD
BEARING HALF	BEARING HALF	BEARING HALF (UPPER & LOWER) STD
885403082525	885403082525	KIT, CRANKSHAFT SEALING RING WITH LOCATING PINS CONSISTING OF :
252503138201	252503138201	OIL SLINGER
1	252503107934	CRANK SHAFT STD. (INTEGRAL TYPE)
2	252503110133	ASSY, FLYWHEEL WITH RING GEAR
3	3520321105	RING GEAR
4	3129900301	BOLT
5	3129940232	LOCKING PLATE
6	253403103102	BALL BEARING
7	3120310533	LOCKING RING (IN CRANKSHAFT TO FIX THE BEARING)
8	3520520003	CRANK SHAFT GEAR
9	13650510091	WOODRUFF KEY 8X13
10	252503138603	SPACER
11	3520303103	ASSY. VIBRATION DAMPER (DOUBLE GROOVE)
12	252303138603	THRUST SPACER
13	252303133202	LOCK (V. DAMPER)
14	252503107801	SEALING RING HALF
14	SEALING RING HALF	SEALING RING HALF
15	LOCATING PIN	LOCATING PIN
15	1869910055	PIN MAIN BEARING SET
16	885403762525	THRUST WASHER SET (STD)
16	885403782525	THRUST WASHER SET (RS II)
16	885403772525	THRUST WASHER SET (RS I)
17	BEARING UPPER HALF RS II	BEARING UPPER HALF RS II
17	BEARING UPPER HALF RS III	BEARING UPPER HALF RS III
17	BEARING UPPER HALF STD	BEARING UPPER HALF STD
17	BEARING UPPER HALF RS III	BEARING UPPER HALF RS III
17	BEARING UPPER HALF RS I	BEARING UPPER HALF RS I
18	BEARING LOWER HALF RS II	BEARING LOWER HALF RS II
18	BEARING LOWER HALF STD	BEARING LOWER HALF STD
18	BEARING LOWER HALF RS I	BEARING LOWER HALF RS I
18	BEARING LOWER HALF RS III	BEARING LOWER HALF RS III
18	BEARING LOWER HALF RS III	BEARING LOWER HALF RS III
19	THRUST WASHER UPPER HALF	THRUST WASHER UPPER HALF (116 MM DIA.) STD
19	THRUST WASHER UPPER HALF	THRUST WASHER UPPER HALF (116 MM DIA.) STD
19	THRUST WASHER UPPER HALF	THRUST WASHER UPPER HALF (116 MM DIA.) STD
20	THRUST WASHER UPPER HALF	THRUST WASHER UPPER HALF (116 MM DIA.) STD
20	THRUST WASHER UPPER HALF	THRUST WASHER UPPER HALF (116 MM DIA.) STD
20	THRUST WASHER UPPER HALF	THRUST WASHER UPPER HALF (116 MM DIA.) STD
21	885403742525	MAIN BEARING SET (RS III) CONSISTING
21	885403702525	MAIN BEARING SET (STD) CONSISTING
21	885403752525	MAIN BEARING SET (RS IV) CONSISTING
21	885403722525	MAIN BEARING SET (RS I) CONSISTING
21	885403732525	MAIN BEARING SET (RS II) CONSISTING
22	252503990148	BARE PISTON SET STD (BS II) CONSISTING
22	252503990150	SET OF PISTON RINGS CONSISTING
23	PISTON	PISTON
23	PISTON	PISTON
24	PISTON PIN	PISTON PIN
24	PISTON PIN	PISTON PIN
25	CIRCLIP	CIRCLIP
25	CIRCLIP RING SET	CIRCLIP RING SET
26	252503990129	SET OF PISTON RING STD CONSISTING
26	252503990150	SET OF PISTON RINGS CONSISTING
26	252503990151	SET OF PISTON RINGS CONSISTING
27	DOUBLE TRAPEZ RING	DOUBLE TRAPEZ RING (GR I)
27	DOUBLE TRAPEZ RING	DOUBLE TRAPEZ RING (GR I)
27	DOUBLE TRAPEZ RING	DOUBLE TRAPEZ RING (GR I)
28	COMPRESSION RING	COMPRESSION RING
28	COMPRESSION RING	COMPRESSION RING
28	COMPRESSION RING	COMPRESSION RING
29	ASSY, OIL CONTROL RING	ASSY, OIL CONTROL RING (GR III)
29	ASSY, OIL CONTROL RING	ASSY, OIL CONTROL RING (GR III)
29	ASSY, OIL CONTROL RING	ASSY, OIL CONTROL RING (GR III)
30	252503150107	ASSY. CON. ROD SERRATED (STD) WITH BUSH
30	252503150125	ASSY. CON. ROD (STD) WITH BUSH
31	885403682525	CON. ROD BUSH SET STD
33	13050507143	PIN CYLINDRICAL 6X14
35	252503153205	SCREW CON. ROD CONNECTING ROD BEARING SET
37	885403652525	BEARING SET FOR CON. ROD. RS II CONSISTING OF
37	885403642525	BEARING SET FOR CON. ROD. RS I CONSISTING OF
37	885403662525	BEARING SET FOR CON. ROD. RS III CONSISTING OF
37	885403622525	BEARING SET FOR CON. ROD (STD) CONSISTING OF
37	885403672525	BEARING SET FOR CON. ROD. RS IV CONSISTS OF
