Каталог запасных частей к технике: Tata LP/LPT 613 LHD (справочная информация). REAR AXLE
1
4
18
19
19
20
21
22
23
25
28
29
30
31
33
34
34
34
34
34
34
34
34
34
34
36
37
38
39
40
41
42
43
47
48
49
50
52
53
58
59
60
61
71
76
76
78
78
78
79
79
79
79
81
81
81
82
82
82
82
82
82
82
82
85
85
87
92
99
99
104
105
106
111
112
112
112
112
112
112
112
112
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
118
119
120
124
124
| Позиция на иллюстрации | Заводской номер детали | Название детали | Цена | |
|---|---|---|---|---|
| 2661 3510 82 02 | 2661 3510 82 02 | Oil Slinger | ||
| 000 997 67 47 | 000 997 67 47 | Oil Seal, Hub Outer (Single Lip) | ||
| 1458 061100 2 | 1458 061100 2 | Internal Circlip 110x4 | ||
| 2643 4230 99 01 | 2643 4230 99 01 | Pole Wheel Rear | ||
| 2643 4230 33 02 | 2643 4230 33 02 | Sensor Mtg. Bracket (Rear) - ABS | ||
| 2643 4230 33 03 | 2643 4230 33 03 | Sensor Mtg. Bracket (Rear) - ABS | ||
| 2632 4210 34 03 | 2632 4210 34 03 | Sensor Bush -ABS | ||
| 2643 5420 99 29 | 2643 5420 99 29 | Sensor -`L Type' (Wheel Speed) . | ||
| 2612 3530 82 01 | 2612 3530 82 01 | Locking Plate | ||
| 2661 3530 61 01 | 2661 3530 61 01 | Locking Plate (Differential Case) | ||
| 2661 3530 80 04 | 2661 3530 80 04 | Hex. Screw | ||
| 2661 3530 78 01 | 2661 3530 78 01 | Dust Seal | ||
| 2661 3530 01 25 | 2661 3530 01 25 | Differential Gear and Spider Kit Consists of: | ||
| 1 | 2661 3500 01 40 | Assy. Rear Axle Complete with Brake ( 28/9 CWP Ratio ) With ABS | ||
| 4 | 2661 3510 01 39 | Assy. Rear Axle Housing with Supporting Tubes, with ABS | ||
| 18 | 2612 3560 86 01 | Spacer | ||
| 19 | 2612 3560 65 01 | Locking Ring | ||
| 20 | 2612 3560 82 02 | Locking Plate | ||
| 21 | 2574 3315 01 02 | Breather | ||
| 22 | 2821 4010 67 01 | Hub Pin Rear | ||
| 23 | 2665 3560 88 01 | Stud M16 | ||
| 25 | 1230 269602 9 | Hex Nut M12X1.5 | ||
| 28 | 2661 3560 82 01 | Oil Catcher, (For ABS) | ||
| 29 | 2661 3510 86 02 | Pressure Ring | ||
| 30 | 2661 3560 77 01 | Oil Seal, Hub Inner (Double Lip) | ||
| 31 | 2661 3560 86 01 | Spacer | ||
| 33 | 2575 3560 31 10 | Taper Roller Bearing, Inner | ||
| 34 | 2661 3560 83 01 | Shim-0.05 Thk. | ||
| 34 | 2661 3560 83 02 | Shim-0.10 Thk. | ||
| 34 | 2661 3560 83 03 | Shim-0.15 Thk. | ||
| 34 | 2661 3560 83 04 | Shim-0.20 Thk. | ||
| 34 | 2661 3560 83 05 | Shim-0.25 Thk. | ||
| 34 | 2661 3560 83 06 | Shim-0.30 Thk. | ||
| 34 | 2661 3560 83 07 | Shim-0.50 Thk. | ||
| 34 | 2661 3560 83 08 | Shim-1.00 Thk. | ||
| 34 | 2661 3560 83 09 | Shim-1.50 Thk. | ||
| 34 | 2661 3560 83 10 | Shim-2.5 Thk. | ||
| 36 | 2612 3560 31 02 | Taper Roller Bearing, Outer | ||
| 37 | 2661 3560 86 02 | Spacer Tube | ||
| 38 | 2661 3560 01 18 | Assy.Rear Hub (For ABS) | ||
| 39 | 2641 4210 37 01 | Brake Drum | ||
| 40 | 2661 3570 79 02 | Rear Axle Shaft | ||
| 41 | 2661 3560 53 02 | Gasket (For Brake Drum with Hub) | ||
| 42 | 2663 3510 72 01 | Magnetic Drain Plug | ||
| 43 | 000 997 05 06 | Screw Plug, Oil Filling | ||
| 47 | 2661 3530 65 01 | Threaded Ring | ||
| 48 | 312 994 12 01 | Locking Plate | ||
| 49 | 2612 3560 82 02 | Locking Plate | ||
| 50 | 1132 399619 1 | Hex. Screw M 8x12 | ||
| 52 | 2612 3530 01 03 | Adjusting Pin | ||
| 53 | 1208 090180 0 | Hex. Thin Nut M 18x1.5 | ||
| 58 | 2661 3510 53 01 | Gasket (Between R.A. Housing & Rear Cover) | ||
| 59 | 2661 3510 01 05 | Assy. Cover Rear Axle Housing | ||
| 60 | 1252 069805 0 | Spring Washer B10 | ||
| 61 | 1132 399818 5 | Hex. Screw M 10x18 | ||
| 71 | 2661 3530 01 21 | Differential Housing Assy. | ||
| 76 | 2661 3530 51 03 | Differential Spider | ||
| 76 | Differential Spider | Differential Spider | ||
| 78 | 2661 3530 54 03 | Differential Bevel Pinion | ||
| 78 | Bevel Gear | Bevel Gear | ||
| 79 | 2661 3530 92 10 | Spherical Washer (Steel) | ||
| 81 | 2661 3530 54 04 | Rear Axle Shaft Gear | ||
| 81 | Gear R.A Shaft | Gear R.A Shaft | ||
| 82 | 2661 3530 92 02 | Thrust Washer, Shaft Gear 1.95 mm | ||
| 82 | 2661 3530 92 03 | Thrust Washer, Shaft Gear 2.00 mm | ||
| 82 | 2661 3530 92 04 | Thrust Washer, Shaft Gear 2.05 mm | ||
| 82 | 2661 3530 92 05 | Thrust Washer, Shaft Gear 2.10 mm | ||
| 82 | 2661 3530 92 06 | Thrust Washer, Shaft Gear 2.15 mm | ||
| 82 | 2661 3530 92 07 | Thrust Washer, Shaft Gear 2.20 mm | ||
| 82 | 2661 3530 92 08 | Thrust Washer, Shaft Gear 2.25 mm | ||
| 85 | 2612 3530 31 01 | Taper Roller Bearing (55x100x26.75) | ||
| 87 | 2661 3530 01 19 | Set Crown Wheel and Pinion (31/8 Ratio) | ||
| 92 | 2661 3530 31 16 | Cylindrical Roller Brg. (Pinion Nose) | ||
| 99 | 2661 3530 31 05 | Taper Roller Brg. (Tail Pinion) | ||
| 104 | 2661 3530 86 32 | Spacer (Between Tail Pinion Brgs.) | ||
| 105 | 2661 3530 65 01 | Threaded Ring | ||
| 106 | 2661 3530 86 68 | Spacer (Between Brg. and Flange) | ||
| 111 | 2661 3530 77 02 | Oil Seal Tail Pinion | ||
| 112 | 2661 3530 83 03 | Shim 0.15 Thick | ||
| 112 | 2661 3530 83 04 | Shim 0.20 Thick | ||
| 112 | 2661 3530 83 05 | Shim 0.25 Thick | ||
| 112 | 2661 3530 83 06 | Shim 0.30 Thick | ||
| 112 | 2661 3530 83 07 | Shim 0.45 Thick | ||
| 112 | 2661 3530 83 08 | Shim 0.50 Thick | ||
| 112 | 2661 3530 83 09 | Shim 1.0 Thick | ||
| 112 | 2661 3530 83 10 | Shim 1.5 Thick | ||
| 115 | 2661 3530 86 37 | Spacer Ring, Tail Pinion 7.64 Thick | ||
| 115 | 2661 3530 86 38 | Spacer Ring, Tail Pinion 7.66 Thick | ||
| 115 | 2661 3530 86 39 | Spacer Ring, Tail Pinion 7.68 Thick | ||
| 115 | 2661 3530 86 41 | Spacer Ring, Tail Pinion 7.72 Thick | ||
| 115 | 2661 3530 86 42 | Spacer Ring, Tail Pinion 7.74 Thick | ||
| 115 | 2661 3530 86 44 | Spacer Ring, Tail Pinion 7.78 Thick | ||
| 115 | 2661 3530 86 46 | Spacer Ring, Tail Pinion 7.82 Thick | ||
| 115 | 2661 3530 86 47 | Spacer Ring, Tail Pinion 7.84 Thick | ||
| 115 | 2661 3530 86 48 | Spacer Ring, Tail Pinion 7.86 Thick | ||
| 115 | 2661 3530 86 49 | Spacer Ring, Tail Pinion 7.88 Thick | ||
| 115 | 2661 3530 86 50 | Spacer Ring, Tail Pinion 7.90 Thick | ||
| 115 | 2661 3530 86 51 | Spacer Ring, Tail Pinion 7.92 Thick | ||
| 115 | 2661 3530 86 52 | Spacer Ring, Tail Pinion 7.94 Thick | ||
| 115 | 2661 3530 86 53 | Spacer Ring, Tail Pinion 7.96 Thick | ||
| 115 | 2661 3530 86 54 | Spacer Ring, Tail Pinion 7.98 Thick | ||
| 115 | 2661 3530 86 55 | Spacer Ring, Tail Pinion 8.00 Thick | ||
| 115 | 2661 3530 86 56 | Spacer Ring, Tail Pinion 8.02 Thick | ||
| 115 | 2661 3530 86 57 | Spacer Ring, Tail Pinion 8.04 Thick | ||
| 115 | 2661 3530 86 58 | Spacer Ring, Tail Pinion 8.06 Thick | ||
| 115 | 2661 3530 86 59 | Spacer Ring, Tail Pinion 8.08 Thick | ||
| 115 | 2661 3530 86 60 | Spacer Ring, Tail Pinion 8.10 Thick | ||
| 115 | 2661 3530 86 63 | Spacer Ring, Tail Pinion 8.12 Thick | ||
| 115 | 2661 3530 86 64 | Spacer Ring, Tail Pinion 8.14 Thick | ||
| 115 | 2661 3530 86 65 | Spacer Ring, Tail Pinion 8.16 Thick | ||
| 115 | 2661 3530 86 66 | Spacer Ring, Tail Pinion 8.18 Thick | ||
| 115 | 2661 3530 86 67 | Spacer Ring, Tail Pinion 8.20 Thick | ||
| 118 | 2661 3530 50 01 | Coupling Flange | ||
| 119 | 2661 3530 82 03 | Dust Cover | ||
| 120 | 2661 3530 65 04 | Hex. Nut (Tail Pinion Coupling Flange) | ||
| 124 | 2641 4230 01 44 | Assy. Brake Chamber Mounting Bracket RH | ||
| 124 | 2641 4230 01 45 | Assy. Brake Chamber Mounting Bracket LH |
