Каталог запасных частей к технике: Tata LP/LPT 613 LHD (справочная информация). MOVING PARTS

Позиция на иллюстрации	Заводской номер детали	Название детали
Con. Rod Bush STD	Con. Rod Bush STD	Con. Rod Bush STD
Bearing Half (Upper & Lower) STD	Bearing Half (Upper & Lower) STD	Bearing Half (Upper & Lower) STD
Bearing Half (Upper & Lower) RS I	Bearing Half (Upper & Lower) RS I	Bearing Half (Upper & Lower) RS I
Bearing Half (Upper & Lower) RS II	Bearing Half (Upper & Lower) RS II	Bearing Half (Upper & Lower) RS II
Bearing Half (Upper & Lower) RS III	Bearing Half (Upper & Lower) RS III	Bearing Half (Upper & Lower) RS III
Bearing Half (Upper & Lower) RS IV	Bearing Half (Upper & Lower) RS IV	Bearing Half (Upper & Lower) RS IV
8854 0308 25 25	8854 0308 25 25	Kit, Crankshaft Sealing Ring with Locating Pins Consisting of :
2525 0313 82 01	2525 0313 82 01	Oil Slinger
1	2525 0310 79 34	Crank Shaft Std. (Integral Type)
2	2525 0311 01 33	Assy. Flywheel with Ring Gear
2	2525 0311 01 26	Assy. Flywheel with Ring Gear
3	352 032 11 05	Ring Gear
4	312 990 03 01	Bolt
5	312 994 02 32	Locking Plate
6	2534 0310 31 02	Ball Bearing
7	312 031 05 33	Locking Ring (In Crankshaft to Fix The Bearing)
8	352 052 00 03	Crank Shaft Gear
9	1365 051009 1	Woodruff Key 8x13
10	2525 0313 86 03	Spacer
11	352 030 31 03	Assy. Vibration Damper (Double Groove)
12	2523 0313 86 03	Thrust Spacer
13	2523 0313 32 02	Lock (V. Damper)
14	2525 0310 78 01	Sealing Ring Half
14	Sealing Ring Half	Sealing Ring Half
15	Locating Pin	Locating Pin
15	186 991 00 55	Pin
16	8854 0376 25 25	Thrust Washer Set (STD) Consisting of :
16	8854 0377 25 25	Thrust Washer Set (RS I) Consisting of :
16	8854 0378 25 25	Thrust Washer Set (RS II) Consisting of :
17	Bearing Upper Half RS II	Bearing Upper Half RS II
17	Bearing Upper Half RS III	Bearing Upper Half RS III
17	Bearing Upper Half RS IV	Bearing Upper Half RS IV
17	Bearing Upper Half RS I	Bearing Upper Half RS I
17	Bearing Upper Half STD	Bearing Upper Half STD
18	Bearing Lower Half RS II	Bearing Lower Half RS II
18	Bearing Lower Half RS I	Bearing Lower Half RS I
18	Bearing Lower Half STD	Bearing Lower Half STD
18	Bearing Lower Half RS IV	Bearing Lower Half RS IV
18	Bearing Lower Half RS III	Bearing Lower Half RS III
19	Thrust Washer Lower Half (116 mm Dia.) RS I	Thrust Washer Lower Half (116 mm Dia.) RS I
19	Thrust Washer Lower Half (116 mm Dia.) RS II	Thrust Washer Lower Half (116 mm Dia.) RS II
19	Thrust Washer Lower Half (116 mm Dia.) STD	Thrust Washer Lower Half (116 mm Dia.) STD
20	Thrust Washer Upper Half (116 mm Dia.) RS I	Thrust Washer Upper Half (116 mm Dia.) RS I
20	Thrust Washer Upper Half (116 mm Dia.) RS II	Thrust Washer Upper Half (116 mm Dia.) RS II
20	Thrust Washer Upper Half (116 mm Dia.) STD	Thrust Washer Upper Half (116 mm Dia.) STD
21	8854 0370 25 25	Main Bearing Set (STD) Consisting of :
21	8854 0372 25 25	Main Bearing Set (RS I) Consisting of :
21	8854 0373 25 25	Main Bearing Set (RS II) Consisting of :
21	8854 0374 25 25	Main Bearing Set (RS III) Consisting of :
21	8854 0375 25 25	Main Bearing Set (RS IV) Consisting of :
22	2525 0399 01 48	Bare Piston Set Std (BS II) Consisting of :
22	2525 0399 01 50	Set of Piston Rings Consisting of:
23	Piston	Piston
23	Piston	Piston
24	Piston Pin	Piston Pin
24	Piston Pin	Piston Pin
25	Circlip	Circlip
25	Circlip	Circlip
26	2525 0399 01 50	Set of Piston Rings Consisting of:
26	2525 0399 01 29	Set of Piston Ring Std Consisting of :
26	2525 0399 01 51	Set of Piston Rings Consisting of:
27	Double Trapez Ring (Gr I)	Double Trapez Ring (Gr I)
27	Double Trapez Ring (Gr I)	Double Trapez Ring (Gr I)
27	Double Trapez Ring (Gr I)	Double Trapez Ring (Gr I)
28	Compression Ring (Gr II)	Compression Ring (Gr II)
28	Compression Ring (Gr II)	Compression Ring (Gr II)
28	Compression Ring (Gr II)	Compression Ring (Gr II)
29	Assy. Oil Control Ring (Gr III)	Assy. Oil Control Ring (Gr III)
29	Assy. Oil Control Ring (Gr III)	Assy. Oil Control Ring (Gr III)
29	Assy. Oil Control Ring (Gr III)	Assy. Oil Control Ring (Gr III)
30	2525 0315 01 07	Assy. Con. Rod Serrated (STD) with Bush
30	2525 0315 01 25	Assy. Con. Rod (STD) with Bush
31	8854 0368 25 25	Con. Rod Bush Set STD Consisting of :
33	1305 050714 3	Pin Cylindrical 6x14
35	2525 0315 32 05	Screw Con. Rod
37	8854 0362 25 25	Bearing Set for Con. Rod (Std) Consisting of :
37	8854 0364 25 25	Bearing Set for Con. Rod. RS I Consisting of :
37	8854 0365 25 25	Bearing Set for Con. Rod. RS II Consisting of :
37	8854 0366 25 25	Bearing Set for Con. Rod. RS III Consisting of :
37	8854 0367 25 25	Bearing Set for Con. Rod. RS IV Consists of :
