Каталог запасных частей к технике: Tata LP/LPT 613 LHD (справочная информация). GEAR BOX HOUSING
1
1
2
3
4
5
6
6
7
11
11
12
15
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
17
19
19
20
21
23
23
23
23
23
27
27
30
31
31
32
33
37
38
39
40
41
42
43
44
45
46
47
48
49
54
55
56
57
58
59
60
61
62
63
63
63
64
64
64
65
66
67
68
68
69
70
73
74
75
76
77
78
79
83
| Позиция на иллюстрации | Заводской номер детали | Название детали | Цена | |
|---|---|---|---|---|
| 2505 2625 82 01 | 2505 2625 82 01 | Oil Slinger (Front Cover) | ||
| 2505 2620 78 03 | 2505 2620 78 03 | Oil Seal | ||
| 321 261 03 33 | 321 261 03 33 | Cover (For PTO Application) | ||
| 2505 2640 53 03 | 2505 2640 53 03 | Gasket (For Cover) | ||
| 2505 2671 34 07 | 2505 2671 34 07 | Stopper Piece Check Plate | ||
| 2505 2671 34 03 | 2505 2671 34 03 | Support Piece Check Plate | ||
| 2505 2600 01 01 | 2505 2600 01 01 | Gear Box Gasket Kit Consisting of : | ||
| 8854 2605 16 13 | 8854 2605 16 13 | Overhauling Kit - GB 40 consisting of : | ||
| Oil Seal | Oil Seal | Oil Seal | ||
| Oil Seal (Front Cover) | Oil Seal (Front Cover) | Oil Seal (Front Cover) | ||
| Shim 0.10 mm Thick | Shim 0.10 mm Thick | Shim 0.10 mm Thick | ||
| Shim 0.20 mm Thick | Shim 0.20 mm Thick | Shim 0.20 mm Thick | ||
| Shim 0.40 mm Thick | Shim 0.40 mm Thick | Shim 0.40 mm Thick | ||
| Shim 0.05 mm Thick | Shim 0.05 mm Thick | Shim 0.05 mm Thick | ||
| Shim 0.80 mm Thick | Shim 0.80 mm Thick | Shim 0.80 mm Thick | ||
| Gasket (GB cover Lower to GB Housing) | Gasket (GB cover Lower to GB Housing) | Gasket (GB cover Lower to GB Housing) | ||
| Gasket (Front cover Top to GB Housing) | Gasket (Front cover Top to GB Housing) | Gasket (Front cover Top to GB Housing) | ||
| Gasket (GB cover RR) | Gasket (GB cover RR) | Gasket (GB cover RR) | ||
| Gasket (GB Top cover) | Gasket (GB Top cover) | Gasket (GB Top cover) | ||
| Hex Collar Nut | Hex Collar Nut | Hex Collar Nut | ||
| Hex Nut | Hex Nut | Hex Nut | ||
| Pressure Spring | Pressure Spring | Pressure Spring | ||
| Pin Main Shaft | Pin Main Shaft | Pin Main Shaft | ||
| 1 | 2505 2604 01 80 | Assy. GBS - 40 - 5 / 6.34 8 BCF PTO provision, Full Remote LHD | ||
| 1 | 2505 2604 01 24 | Assy. GBS - 40 - 5 / 6.34 6 BCF, Full Remote LHD | ||
| 2 | 2505 2610 37 22 | Gear Box Housing (6.34 Ratio) | ||
| 3 | 1305 090920 9 | Cylindrical Pin 10 H 8x20 | ||
| 4 | 000 997 00 06J | Plug Oil Filling | ||
| 5 | 2506 2610 72 03 | Magnetic Drain Plug (Hex head type) | ||
| 6 | 2505 3014 53 01 | Gasket | ||
| 6 | Gasket Front Cover Lower | Gasket Front Cover Lower | ||
| 7 | 2505 3014 47 01 | Front Cover Lower | ||
| 11 | 2505 2625 53 01 | Gasket (Fr. Cover Top to Hsg.) | ||
| 11 | Gasket Front CoverUpper | Gasket Front CoverUpper | ||
| 12 | 2505 3013 47 01 | Gear Box Housing Cover Front Top | ||
| 15 | 2505 2625 78 08 | Oil Seal | ||
| 16 | 2505 3013 86 01 | Butting Ring 2.90 mm Thick | ||
| 16 | 2505 2625 86 01 | Butting Ring 2.95 mm Thick | ||
| 16 | 2505 3013 86 02 | Butting Ring 3.00 mm Thick | ||
| 16 | 2505 2625 86 02 | Butting Ring 3.05 mm Thick | ||
| 16 | 2505 3013 86 03 | Butting Ring 3.10 mm Thick | ||
| 16 | 2505 2625 86 03 | Butting Ring 3.15 mm Thick | ||
| 16 | 2505 3013 86 04 | Butting Ring 3.20 mm Thick | ||
| 16 | 2505 2625 86 04 | Butting Ring 3.25 mm Thick | ||
| 16 | 2505 3013 86 05 | Butting Ring 3.30 mm Thick | ||
| 16 | 2505 2625 86 05 | Butting Ring 3.35 mm Thick | ||
| 16 | 2505 3013 86 06 | Butting Ring 3.40 mm Thick | ||
| 16 | 2505 2625 86 06 | Butting Ring 3.45 mm Thick | ||
| 16 | 2505 3013 86 07 | Butting Ring 3.50 mm Thick | ||
| 16 | 2505 3013 86 08 | Butting Ring 3.60 mm Thick | ||
| 17 | 2505 3015 37 01 | Gear Case Cover Rear | ||
| 19 | 321 261 00 31 | Adaptor | ||
| 20 | 321 260 00 86 | Assy. Threaded Bush | ||
| 21 | 153 264 00 55 | Plug Speedo Drive | ||
| 23 | 312 283 17 52 | Shim 0.05 mm Thick | ||
| 23 | 312 283 10 52 | Shim 0.1 mm Thick | ||
| 23 | 312 283 11 52 | Shim 0.2 mm Thick | ||
| 23 | 312 283 12 52 | Shim 0.4 mm Thick | ||
| 23 | 312 283 21 52 | Shim 0.8 mm Thick | ||
| 27 | 352 261 07 80 | Gasket (Gear Case Cover Rear) | ||
| 27 | Gasket Rear Cover | Gasket Rear Cover | ||
| 30 | 2505 2671 37 55 | Gear Case Cover Top (Lower Half) | ||
| 31 | 2505 3014 53 01 | Gasket | ||
| 31 | Gasket Top Cover | Gasket Top Cover | ||
| 32 | 2505 3012 88 01 | Stud | ||
| 33 | 2505 2671 67 01 | Pin Swing Lever | ||
| 37 | 2668 3515 01 02 | Pressure relief Valve | ||
| 38 | 2505 3011 67 01 | Thrust Pin (Reverse Indicator Switch) | ||
| 39 | 312 993 42 01 | Pressure Spring (Reverse Indicator Switch) | ||
| 40 | 2654 5450 01 34 | Reverse Indicator Switch | ||
| 41 | 2505 2670 51 05 | Swing Lever - 1st Speed | ||
| 42 | 2505 3012 92 01 | Washer (Swing Lever) | ||
| 43 | 2505 2671 34 09 | Pressure Piece for Check Plate | ||
| 44 | 2505 2671 87 02 | Pressure Spring for Pressure Piece | ||
| 45 | 321 997 01 03 | Slotted Plug | ||
| 46 | 2505 2671 34 10 | Interlocking Pin | ||
| 47 | 321 993 06 01 | Pressure Spring for Interlocking Pin | ||
| 48 | 1608 250240 1 | Sealing Plug M 24x1.5 | ||
| 49 | 321 260 08 46 | Assy. Check Plate | ||
| 54 | 321 265 08 05 | Selector Shaft for First Speed | ||
| 55 | 321 265 18 05 | Selector Shaft (2/3) | ||
| 56 | 321 265 19 05 | Selector Shaft (4/5) | ||
| 57 | 322 265 03 05 | Selector Shaft (For Reverse Gear) | ||
| 58 | 322 265 01 23 | Gear Shift Dog (For First Gear) | ||
| 59 | 321 265 12 02 | Selector Fork (2/3) | ||
| 60 | 2505 2651 51 02 | Selector Fork (4/5) | ||
| 61 | 321 265 13 01 | Selector Fork (For 1st Speed Gear) | ||
| 62 | 2505 2651 51 01 | Selector Fork (For Reverse Gear) | ||
| 63 | 312 993 10 01 | Pressure Spring | ||
| 64 | 1595 010110 2 | Steel Ball 11 mm dia. | ||
| 65 | 312 265 10 36 | Clamp (Selector Shaft to Gear Box Housing) | ||
| 66 | 312 994 03 32 | Locking Plate (Selector Shaft to Gear Box Housing) | ||
| 67 | 2505 2671 37 56 | Cover Top (Upper Half) | ||
| 68 | 2507 2671 31 05 | Needle Bearing | ||
| 69 | 2505 2670 51 04 | Shifter Finger | ||
| 70 | 2505 2670 79 09 | Selector & Shifter Shaft | ||
| 73 | 1706 160251 8 | Oil Seal | ||
| 74 | 2507 2671 78 03 | Scraper Ring | ||
| 75 | 2507 2670 60 13 | Shifting Lever | ||
| 76 | 2505 2671 82 22 | Cap | ||
| 77 | 2505 2671 77 01 | Bellow | ||
| 78 | 1427 020250 1 | Hose Clip 25 | ||
| 79 | 2506 2671 53 01 | Gasket (Between Upper & Lower Half) | ||
| 83 | 321 265 08 49 | Sliding Key |
